Bamboo As Building Material

Bamboo As Building Material

Bamboo has a long and well-established tradition as a building material through out the world’s tropical and sub-tropical regions. It is widely used for many forms of construction, in particular fo...
Bamboo has a long and well-established tradition as a building material through out the world’s tropical and sub-tropical regions. It is widely used for many forms of construction, in particular for housing in rural areas. Bamboo is a renewable and versatile resource, characterized by high strength and low weight, and is easily worked using simple tools. It is widely recognized as one of the most important non-timber forest resources due to the high socio-economic benefits from bamboo based products. It is estimated that there are 1200 species growing in about 14.5 million hectares area. Most of them grow in Asia, Africa and Latin America.
Bamboo is a renewable and versatile resource, characterized by high strength and low weight, and is easily worked using simple tools. It is widely recognized as one of the most important non-timber forest resources due to the high socio-economic benefits from bamboo based products. Bamboo is the world’s fastest growing woody plant.
TENSILE STRENGTH
Bamboo is able to resist more tension than compression. The fibres of bamboo run axial. In the outer zone are highly elastic vascular bundle, that have a high tensile strenght. The tensile strenght of these fibres is higher than that of steel, but it’s not possible to construct connections that can transfer this tensile strength. Slimmer tubes are superior in this aspect too. Inside the silicated outer skin, axial parallel elastical fibers with a tensile strength upto 400 N/mm2 can be
found. As a comparison, extremely strong wood fibers can resist a tension upto 50 N /mm2.
COMPRESSIVE STRENGTH
Compared to the bigger tubes, slimmer ones have got, in relation to their cross-section, a higher compressive strength value. The slimmer tubes possess better material properties due to the fact that bigger tubes have got a minor part of the outer skin, which is very resistant in tension. The portion of lignin inside the culms affects compressive strength, whereas the high portion of cellulose influences the buckling and the tensile strength as it represents the building substance of the bamboo fibers.
ELASTIC MODULUS
The accumulation of highly strong fibers in the outer parts of the tube wall also work positive in connection with the elastic modulus like it does for the tension, shear and bending strength. The higher the elastic modulus, the higher is the quality of the bamboo. Enormous elasticity makes it a very useful building material in areas with very high risks of earthquakes.
ANISOTROPIC PROPERTIES
Bamboo is an anisotropic material. Properties in the longitudinal direction are completely different from those in the transversal direction. There are cellulose fibers in the longitudinal direction, which is strong and stiff and in the transverse direction there is lignin, which is soft and brittle.
SHRINKAGE
Bamboo shrinks more than wood when it loses water. The canes can tear apart at the nodes. Bamboo shrinks in a cross section of 10-16 % and a wall thickness of 15-17 %. Therefore it is necessary to take necessary measures to prevent water loss when used as a building material.
FIRE RESISTANCE
The fire resistance is very good because of the high content of silicate acid. Filled up with water, it can stand a temperature of 400° C while the water cooks inside.
